Working Principles and Technical Features

The small combined air filling and cutting machine integrates inflation and precision cutting into one automated system. It operates through a pneumatic control mechanism and high-precision mechanical components. A built-in scroll-type air pump generates adjustable airflow ranging from 0.3 to 0.9 MPa, distributed uniformly via multi-orifice nozzles. The cutting system uses a servo motor and optical grating positioning to achieve cutting accuracy within ±0.2 mm. The machine adopts a modular design that includes pneumatic control, material feeding, temperature regulation (optional), and cutting modules, all synchronized by a PLC.

Standard configurations include a 5-inch HMI touchscreen for adjusting over 20 parameters, such as pressure, length, and speed. The power rating is 2.2 kW, with a maximum speed of 25 m/min. It processes materials with thicknesses ranging from 0.03 to 0.25 mm. Key components are made from stainless steel, and the vacuum adsorption platform ensures material flatness. Operational noise remains below 70 dB.

Applications and Production Scope

This machine is used to produce inflatable packaging, such as air column bags and bubble films. It achieves daily outputs of 8,000–15,000 linear meters for products with widths ranging from 100 to 600 mm. Medical applications include ice packs and inflatable splints, with medical-grade models featuring HEPA filters. For food packaging, it produces inflatable candy wrappers and coffee bean buffers, using FDA-compliant materials. The machine is also used for industrial protective cushions and sports protective gear.

Technical Parameters and Innovations

The standard working width is 500 mm, with customization available from 300–1200 mm. The inflation pressure reaches a maximum of 0.9 MPa, with a flow range of 5–30 L/min. Cutting precision is ±0.1 mm, with a maximum cutting rate of 60 cycles per minute. The optional temperature control system operates up to 200°C with ±1°C accuracy.

The dual air path allows for simultaneous inflation and suction. IoT-enabled models support 4G/5G connectivity for remote monitoring and diagnostics. Energy consumption is 30% lower than conventional models, with standby power consumption under 100 W. The system includes two-hand operation buttons and safety light curtains conforming to CE standards.

An intelligent compensation system automatically adjusts parameters based on environmental conditions, while machine learning optimizes production settings. Modular components allow for quick function changes, improving both flexibility and efficiency.

Why Choose Us

We offer state-of-the-art machines designed for maximum efficiency and precision. With years of industry experience, our solutions guarantee high-quality performance, superior durability, and innovative technologies. Whether you're in packaging, medical, or industrial sectors, our machines are built to meet your unique needs. Contact us today to explore how our equipment can help optimize your production processes!
